INTEL Core i5 14600KF Tray 3.5 GHz,24MB, Socket 1700

Core™ i5 processor 14600KF

• Product Collection Intel® Core™ i5 Processors (14th gen)
• Code Name Products formerly RAPTOR LAKE
• Vertical Segment Desktop
• Processor Number i5-14600KF
• Lithography Intel 7
• Use Conditions PC/Client/Tablet

• Total Cores 14
• # of Performance-cores 6
• # of Efficient-cores 8
• Total Threads 20
• Max Turbo Frequency 5.3 GHz
• Performance-core Max Turbo Frequency 5.3 GHz
• Efficient-core Max Turbo Frequency 4 GHz
• Performance-core Base Frequency 3.5 GHz
• Efficient-core Base Frequency 2.6 GHz
• Cache 24 MB Intel® Smart Cache
• Total L2 Cache 20 MB
• Processor Base Power 125 W
• Maximum Turbo Power 181 W

• Max Memory Size (dependent on memory type) 192 GB
• Memory Types
  • Up to DDR5 5600 MT/s
  • Up to DDR4 3200 MT/s
• Max # of Memory Channels 2
• Max Memory Bandwidth 89.6 GB/s

• Direct Media Interface (DMI) Revision 4.0
• Max # of DMI Lanes 8
• Scalability 1S Only
• PCI Express Revision 5.0 and 4.0
• PCI Express Configurations Up to 1x16+4, 2x8+4
• Max # of PCI Express Lanes 20

• Sockets Supported FCLGA1700
• Max CPU Configuration 1
• Thermal Solution Specification PCG 2020A
• TJUNCTION 100°C
• Package Size 45.0 mm x 37.5 mm

• Intel® Gaussian & Neural Accelerator 3.0
• Intel® Thread Director : Yes
• Intel® Deep Learning Boost (Intel® DL Boost) on CPU : Yes
• Intel® Speed Shift Technology : Yes
• Intel® Turbo Boost Technology 2.0
• Intel® Hyper-Threading Technology : Yes
• Intel® 64 : Yes
• Instruction Set 64-bit
• Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
• Idle States : Yes
• Enhanced Intel SpeedStep® Technology : Yes
• Thermal Monitoring Technologies : Yes
• Intel® Volume Management Device (VMD) : Yes

• Intel® Standard Manageability (ISM) : Yes
• Intel® Control-Flow Enforcement Technology : Yes
• Intel® AES New Instructions : Yes
• Secure Key : Yes
• Intel® OS Guard : Yes
• Execute Disable Bit : Yes
• Intel® Boot Guard : Yes
• Mode-based Execute Control (MBEC) : Yes
• Intel® Virtualization Technology (VT-x) : Yes
• Intel® Virtualization Technology for Directed I/O (VT-d) : Yes
• Intel® VT-x with Extended Page Tables (EPT) : Yes
